ESAB Caddy Tig 2200i AC/DC

Features:
Superior Arc characteristics –Smooth, Stable performance.
Generator Compliant - Suitable for use with Generators (recommended; ES 150i Pro 5KW & ES 200i Pro, ET 200iP Pro 7KW).
Easy to Use –Set the welding current and weld with excellent result
Practical Design -makes the power source easy to carry which enables use at almost any work site
Robust Design –IP23S Designed for Fabrication Shop or Site application.
PFC ensures a stable arc, resistant to power fluctuations even while working on long extension cables up to 100m
Optional analogue remote control

Specifications:
Primary Voltage 1ph: 115/230 VAC ± 15%, 1ph, 50/60 Hz
Input Supply Plug: 15A
Maximum Output: 200A
Rated KVA: 6.9 kVA
Open Circuit Voltage: 78 V DC
Energy Save Mode: 50 W
MMA Welding Output:
200 A / 28.0 V @ 25% Duty Cycle
129 A / 25.2 V @ 60% Duty Cycle
100 A / 24.0 V @ 100% Duty Cycle
TIG Welding Output:
200 A / 18.0 V @ 25% Duty Cycle
129 A / 15.2 V @ 60% Duty Cycle
100 A / 14.0 V @ 100% Duty Cycle
Current Range: 10 – 200 A
Power factor at maximum current:
MMA: 0.99
TIG: 0.99
VRD: <30V
Operating Temperature: -10 to +40 °C (+14 to +104 °F)
Enclosure Class: IP23S
Certification Mark: ETL
Dimensions: 403 x 153 x 264 mm
Weight :9.6 kg
